Protective foam packaging, made easy with one touch.
The SelectFoam/Tiger is a fully electric foam-in-place packaging system that produces protective foam cushions with just the press of a button. The film bag is automatically filled with expanding liquid foam, either in batch production or directly at the packing station. As the foam expands and solidifies, it conforms to the shape of the packaged product, creating a secure mold that absorbs impact and prevents shifting during transit. This process provides reliable, custom-fit protection for a wide range of packaging needs.
Equipped with advanced bag sealing technology, fast cycle speeds, and a user-friendly 10.2-inch display, the SelectFoam/Tiger allows easy adjustment of bag size and foam volume, programming of packaging sequences. The system commonly runs 18-inch (47 cm) wide film and supports seamless integration into existing packaging workflows. Designed for performance and flexibility, it’s ideal for operations that require consistent, high-quality protective packaging on demand.
Clean. Controlled. Custom-Fit—Every Time.
No hand-patting, no repositioning film—Tiger automates the tricky parts for smoother, faster workflows than shipping foam bag.
SelectFoam/Tiger runs on compact film bag and liquid foam—used only when needed. No bulky blocks, no overstock, no wasted space.
Molded foam is rigid and product-specific, requiring custom tooling. Foam-in-bag instantly conforms to any shape—no molds, no delays.
SelectFoam/Tiger delivers repeatable results with preset parameters and automatic sealing. Hand-patted or handheld foam often varies with operator skill, angle, and timing.
Easily switch between products of different sizes—no tooling changes, no delays.
SelectFoam/Tiger’s touchscreen interface and preset programs make it easy for any operator—no specialized training needed.
|
Dimensions
|
1065 x 910 x1920 mm
|
|---|---|
|
Film Size |
47 cm W available (18.5-in W) |
|
Production Rate |
(10) 47 cm （18.5-in）bags per minute, 50% foam-filled |
|
Electrical Power |
220V, 16A |
The TIGER system does not use pre-made bags.
It works with roll film, and the bag length is adjustable based on your machine settings.
If the packed product is longer than 1 meter, we usually recommend using multiple foam bags rather than one extra-long bag. This offers better protection and is more practical during operation.
The Dispenser Solution is used to treat the mixing nozzle after each foaming cycle. Its purpose is to dilute residual material on the nozzle and help prevent buildup during operation.
There is also a separate cleaning solution used for equipment maintenance and deep cleaning. This item cannot be exported, but it can be sourced locally on your side.
The consumable for the Tiger Foam-in-Bag system is not a pre-made bag roll. It is a roll of folded film.
When the operator sets the bag length and starts bag production, the machine automatically creates the bag during the feeding process. At the same time, it seals the side edges of the bag while the nozzle begins injecting the A & B chemicals into the bottom area.
In other words, the bag is formed and filled almost simultaneously — all within one continuous process.
This video explains how the Tiger machine produces foam-in-bag packaging step by step. ➡️ Video Guide
