Dual Servo Case Erector DKXM-500 / DKXL-650

Feature of Dual Servo Case Opener

Easy Operation and Maintenance: Simple design for straightforward operation and low maintenance.
High Automation: Integrates a robotic arm and five servo drives for automated efficiency.
Quiet and Gentle: Operates quietly and maintains the integrity of cases.
Continuous Operation: Features a tilt-style case storage that allows for continuous replenishment without downtime.
Seamless Integration: Compatible with both upstream and downstream equipment for smooth workflow integration.
Accurate Case Handling: Uses a variable frequency motor to drive case movement, ensuring precise box alignment and positioning.
Space Efficient: Compact design that requires minimal floor space.
Customizable: Available in custom configurations to meet specific industry needs.

Model	DKXM-500
Production Efficiency (cartons/min)		5-15
Case Size (cannot process maximum and minimum sizes simultaneously)	Length (mm)	280-500
	Width (mm)	180-400
	Height (mm)	150-400
Motor Power (KW)		0.8
Air Source Pressure (Mpa)		0.6-0.8
Machine Weight (KG)		320
Machine Size (L×W×H) (mm)		2007x1895x1400
Power Supply		220V 50Hz
Sealing		≤60 mm width Tape
** The specific case unpacking speed depends on the size and quality of the case.

( Specification of SelectAutomation-DKXM-500 )

Model	DKXL-650
Production Efficiency (cartons/min)		5-15
Case Size (cannot process maximum and minimum sizes simultaneously)	Length (mm)	280-660
	Width (mm)	180-500
	Height (mm)	150-500
Motor Power (KW)		0.8
Air Source Pressure (Mpa)		0.6-0.8
Machine Weight (KG)		450
Machine Size (L×W×H) (mm)		2390x2000x1340
Power Supply		220V 50Hz
Sealing		≤60 mm width Tape
** The specific case unpacking speed depends on the size and quality of the case.

( Specification of SelectAutomation-DKXL-650 )
